Cycle Bending Test
|
1. Bending load: 200g, Angle: ±120°, Bending speed: 45 cycle/min, Bending cycles: 1200 cycles. 2. After test, no appearance defects. |
|
Cores Resistance
|
16AWG: 14.6Ω/km 22AWG: 59.4Ω/km
18AWG: 23.2Ω/km 24AWG: 94.2Ω/km
20AWG: 36.7Ω/km
|
|
Loading Durability Test
|
1. SR and DC plug of finished product loads 9kg weight, duration of load 1min.
2. The cable pulled away from the end position of the outer mold SR less than 2mm.
Appearance: no damage.
|
| Environmental Requirements |
1. All materials used must conform “RoHS2.0, Reach, CA Prop65, Ortho Benzene 18P, PAHS”.
2. Disable red phosphorus.
|
| Special Note | Specification of DC plug and conductor, length of wire, SR model and color of jacket can customized according to customers. |
